พัดลมอุตสาหกรรมขนาดใหญ่ HVLS Fan / Big Fan

HVLS มาจาก High-Volume, Low-Speed หรือเรียกกันว่า พัดลมยักษ์ เป็นพัดลมที่ใช้ทั่วไปในพื้นที่ขนาดใหญ่ เช่น โรงงานอุตสาหกรรม คลังสินค้า โรงยิม และอาคารเกษตรกรรม พัดลม HVLS ได้รับการออกแบบมาเพื่อเคลื่อนย้ายอากาศปริมาณมากด้วยความเร็วรอบต่ำ โดยทั่วไปอยู่ระหว่าง 50 ถึง 150 รอบต่อนาที (RPM)

ลักษณะเฉพาะที่สำคัญของพัดลม HVLS คือเส้นผ่านศูนย์กลางขนาดใหญ่ ซึ่งมีขนาดตั้งแต่ 2 ถึง 7 เมตร ขนาดใหญ่นี้ช่วยให้สามารถเคลื่อนย้ายอากาศปริมาณมากโดยใช้พลังงานน้อยที่สุด และ สร้างกระแสลมที่นุ่มนวลและเคลื่อนที่ช้าๆ ซึ่งจะหมุนเวียนและผสมอากาศในพื้นที่อย่างมีประสิทธิภาพมากกว่าพัดลมความเร็วสูงแบบเดิม

ประโยชน์ คือ คุณภาพอากาศภายในอาคารที่ดีขึ้น การกระจายอุณหภูมิที่ดีขึ้น และความสบายที่เพิ่มขึ้นสำหรับผู้อยู่อาศัย สามารถช่วยลดการแบ่งชั้นของอากาศร้อนและเย็น ลดการควบแน่น และเพิ่มการระบายอากาศโดยรวม นอกจากนี้ยังมีส่วนช่วยในการประหยัดพลังงานโดยลดการพึ่งพาเครื่องปรับอากาศและระบบทำความร้อนในบางสภาพแวดล้อมได้





แบบเกียร์ (Gear type) : พัดลมแบบเกียร์ HVLS ใช้ชุดเกียร์เพื่อส่งกำลังจากมอเตอร์ไปยังใบพัด กระปุกเกียร์ประกอบด้วยชุดเกียร์ที่ช่วยให้มอเตอร์หมุนด้วยความเร็วสูงในขณะที่ลดความเร็วในการหมุนของใบพัด ความเร็วที่ลดลงนี้ทำให้ได้ขนาดเส้นผ่านศูนย์กลางพัดลมที่ใหญ่ขึ้นและการไหลเวียนของอากาศที่มีประสิทธิภาพที่ความเร็วต่ำ

-ระบบเกียร์ให้แรงบิดสูง ทำให้พัดลมสามารถเคลื่อนย้ายอากาศปริมาณมากได้อย่างมีประสิทธิภาพ

-กระปุกเกียร์จะมีราคาถูกกว่าเทคโนโลยีมอเตอร์ทางเลือกบางประเภทช่วยประหยัดค่าใช้จ่าย

-ระบบเกียร์สามารถรองรับขนาดเส้นผ่านศูนย์กลางพัดลมที่ใหญ่ขึ้น ทำให้เหมาะสำหรับการใช้งานในอุตสาหกรรม หรือเชิงพาณิชย์ที่ต้องการ การไหลเวียนของอากาศสูง



Industrial Type (Gear type) HVLS FAN


 Model Diameter
(FT)
Diameter
(mm)
Voltage
(V)
Frequency
(Hz)
Blade
(pc)
Power
(kW)
Speed
(rpm)
Noise Level
(dB)
Weight
(kg)
Total Height
(m)
Minimum Height
from ceiling
(mm)
Air volume
(m³/min)
Coverage area
(m²)
 AWF-73  24 7300  220 V 50-60 6 1.50 50 60 118 10-12 1200 10700  1200
 380 V
 AWF-66  22 6700  220 V 50-60
6 1.50 56 60 115 8-10 1200 9800 1100
 380 V
 AWF-61  20 6000  220 V 50-60 6 1.50 58 60 113 8-10 1200 8400 1000
 380 V
 AWF-55  18 5400  220 V 50-60 6 1.50 62 60 108 7-9 1200 6700 900
 380 V
 AWF-49  16 4800  220 V 50-60 6 1.10 64 58 104 6-8 1200 5800 650
 380 V
 AWF-42  14 4200  220 V 50-60 6 1.10 70 58 100 5-7 1200 4500 500
 380 V
 AWF-30  10 3000  220 V 50-60 6 0.75 106 56 85 4-6 1000 2700 200
 380 V
 AWF-21  7 2100  220 V 50-60 6 0.75 135 56 80 3-5 1000 2100  100
 380 V







แบบไม่มีเกียร์ (Gearless type) : พัดลม HVLS จะใช้ระบบมอเตอร์ขับเคลื่อนโดยตรงแทน ในระบบนี้ มอเตอร์จะเชื่อมต่อโดยตรงกับฮับพัดลม ทำให้ไม่ต้องใช้เกียร์ การไม่มีเกียร์ช่วยให้การออกแบบเรียบง่ายและกะทัดรัดยิ่งขึ้น

-ระบบ Gearless มีชิ้นส่วนที่เคลื่อนไหวน้อยกว่า ทำให้ลดความจำเป็นในการบำรุงรักษาและการหล่อลื่นตามปกติ มีการค่าบำรุงรักษาต่ำกว่า  แบบเกียร์

-เงียบกว่าการไม่มีเกียร์ช่วยลดเสียงรบกวนที่เกิดขึ้นระหว่างการทำงาน

-ประสิทธิภาพการใช้พลังงานที่สูงขึ้นระบบไร้เกียร์ขจัดการสูญเสียพลังงานที่เกี่ยวข้องกับกระปุกเกียร์ ส่งผลให้ประสิทธิภาพการใช้พลังงานสูงขึ้นเล็กน้อย

-ต้นทุนเริ่มต้นที่สูง ระบบไร้เกียร์อาจมีต้นทุนเริ่มต้นที่สูงขึ้นเนื่องจากเทคโนโลยีมอเตอร์ที่ก้าวหน้ากว่า



BLDC type (Gearless type)  HVLS FAN


Model Diameter
(FT)
Diameter
(mm)
Voltage
(V)
Frequency
(Hz)
Blade
(pc)
Power
(kW)
Speed
(rpm)
Noise Level
(dB)
Weight
(kg)
Total Height
(m)
Minimum Height
from ceiling
(mm
Air volume
(m³/min)
Coverage area
(m²)
ADF-73(D6A) 24 7300 220 V 50-60 6 1.40 42 42 102 10-12 800 12000  1320
380 V
ADF-61(D6A) 20 6100 220 V 50-60 6 1.30 60 42 94 8-10 800 9800 1100
380 V
ADF-55(D6A) 18 5500 220 V 50-60 6 1.10 65 42 90 7-9  800 7200 1000
380 V
ADF-49(D6A) 16 4900 220 V 50-60 6 0.90  65 42 82 6-8 800 5600 750
380 V
ADF-45(D6A)  15 4500 220 V 50-60 6 0.62 65 42 69 6-8 800 5100 650
380 V
ADF-42(D6A) 14 4200 220 V 50-60 6 0.55 72 42  67 5-7 800 5000 600
380 V
ADF-38(D6A) 13 3800 220 V 50-60 6 0.50  75 42 64 5-7 800 3200 400
380 V
ADF-36(D6A) 12 3600 220 V 50-60 6 0.44 80 42 62 4-6 600 2980 290

380 V
ADF-30(D6A)  10 3000 220 V 50-60 6 0.35 115 42 57 4-6 600 2700 200
380 V

ADF-24(D6A)

8 2400 220 V 50-60 6 0.20 120 42 54 3-5 600 2300 120
380 V





Compare with Wall Fan
 HVLS FAN



WALL FAN

 over 1600 M per unit with 13500 m / min,
full space coverd with its 7.3 m diameter fan blade.

     Area Coverage

Wind can only reach to the area in the
of the fan, can not work well if people move frequently.

Installation on ceiling,simple
and elegant,space saving

         Convenience


Mounted on the wall or standing on floor,
consume lots of space


Tridimensional and natural breeze from all directions,
with most comfortable wind speed 1-3 m/s, with
less noise

     Comfortable Level

High speed wind and noisy during
operation,not comfortable

 Almost zero maintenance under proper installation.

         Maintenance

 Need maintenance and clean frequently

 8-10 years.

         Life span

 3-5 years.




Fan Diameter
7.3 0.75
Power ( kW )
1.5 0.36
Air Flow ( m3 / min )
13500 300
Effective Area ( m3 )
1500 30
Factory Area
9000 9000
Total Units installed 6 300
Total Kw installed 9 108
Consumption / Year
@10hrs / day @26 days / mth
28080 336960




ADVANTAGES

 PRODUCTADVANTAGES

    • Large area coverage more than 1000 m2
                                                                                             •  Tridimensional wind from all directions
                                                                                             •  Natural, comfortable, gentle breeze
                                                                                             •  Maintenance free, long life span
                                                                                             •  Essentially Slint quieter than a human conversation
                                                                                             •  Space saving and elegant looking



Application
 As the leading brand In HVLS fans, SMART KOOL has a complete product portfolio. With 2.4 M to 7.3 M in diameter , our products have a wide  application range and remarkable effect,as well as proven superb quality.

 •  Factory
                                                                           •  Workshop
                                                                           •  Manufacturing
                                                                           •  Warehouse
                                                                           •  Logistic Center
                                                                           •  Airport
                                                                           •  Metro Station
                                                                           •  Waiting Room
                                                                           •  Garage
                                                                           •  Gym
                                                                           •  Restaurant
                                                                           •  Dairy Farm


Bigfan HVlS FAN พัดลมอุตสาหกรรมขนาดใหญ่ พัดลมโรงงาน พัดลมขนาดใหญ่



Mounting & Detail

- Designed with user 's comfort and safety in mind

- Custom mounting  systems for customers

- Fan can be mounted to different construction profile

- Safety cable secure the fan to mounting structure

 Benefits of HVLS ceiling fan

- Energy saving  and environment-friendly

- Provide low operating cost to the customers and free manintenance

- Low noise and improve air movement. Users get natural air flow.

- Improve employee comfort & increase productivity

- High-Performance Interverter

- Remove condensation, corrosion and protecting surfaces of metal or machine.

- Prevent the growth of mould, mildew and bacteria associated with high humidity.

- Compliments existing systems.

- Creating a safer working environment, eliminating health and safety concerns as well as unnecessary renovations.
